Model Parameters

The optimization model parameters with the input data must follow the schema below for each table. To create these tables we currently use CSV files that follow this same schema and then convert them into tables using TulipaIO, as shown in the basic example of the Tutorials section.

The schemas can be found in the input-schemas.json. For more advanced users, they can also access the schemas at any time after loading the package by typing TulipaEnergyModel.schema_per_table_name in the Julia console. Here is the complete list of model parameters in the schemas per table (or CSV file):

Optional tables/files and their defaults

The following tables/files are allowed to be missing: "assets_rep_periods_partitions", "assets_timeframe_partitions", "assets_timeframe_profiles", "flows_rep_periods_partitions", "group_asset", "profiles_timeframe".

  • For the partitions tables/files, the default value are specification = uniform and partition = 1 for each asset/flow and year
  • For the profiles tables/files, the default value is a flat profile of value 1.0 p.u.
  • If no group table/file is available there will be no group constraints in the model

Table 1 : asset

asset

  • Description: Unique identifier with the name of the asset.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

capacity

  • Description: Capacity for one unit of the asset (is therefore multiplied by number of existing plus number of invested assets).

  • Type: DOUBLE

  • Unit of measure: MW

  • Default: 0

ConstraintsValue
minimum0

capacity_storage_energy

  • Description: Capacity of one storage unit.

  • Type: DOUBLE

  • Unit of measure: MWh

  • Default: 0

ConstraintsValue
minimum0

consumer_balance_sense

  • Description: Is the sense of the consumer balance constraint, equal to, greater than or less than.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: ==

ConstraintsValue
oneOfAny["==", ">=", "<="]

discount_rate

  • Description: e.g. 0.05 is 5 %. discount rate for the annuity calculation.

  • Type: DOUBLE

  • Unit of measure: ratio

  • Default: 0

ConstraintsValue
minimum0

economic_lifetime

  • Description: Economic lifetime of the unit for annuity calculation.

  • Type: INTEGER

  • Unit of measure: years

  • Default: 1

ConstraintsValue
minimum0

energy_to_power_ratio

  • Description: Fixed ratio between the energy storage capacity [MWh] and the discharge/charge capacity [MW] for energy storage investments where storage_method_energy = false.

  • Type: DOUBLE

  • Unit of measure: h

  • Default: 0

ConstraintsValue
minimum0

group

  • Description: Group to which the asset belongs to (null/empty/missing -> no group).

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

investment_integer

  • Description: Whether investment decisions are using integer variables.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

investment_integer_storage_energy

  • Description: Whether investment for storage energy is integer or continuous. It only applies for energy storage investments where storage_method_energy = true.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

investment_method

  • Description: How investments are treated.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: none

ConstraintsValue
oneOfAny["none", "simple", "compact"]

is_seasonal

  • Description: Whether seasonal storage (e.g., hydro) or not (e.g., battery)

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

max_ramp_down

  • Description: Maximum ramping down rate as a portion of the capacity of asset.

  • Type: DOUBLE

  • Unit of measure: p.u./h

  • Default: 0

ConstraintsValue
minimum0

max_ramp_up

  • Description: Maximum ramping up rate as a portion of the capacity of asset.

  • Type: DOUBLE

  • Unit of measure: p.u./h

  • Default: 0

ConstraintsValue
minimum0

min_operating_point

  • Description: Minimum operating point or minimum stable generation level defined as a portion of the capacity of asset.

  • Type: DOUBLE

  • Unit of measure: p.u.

  • Default: 0

ConstraintsValue
maximum1
minimum0

ramping

  • Description: Whether asset has ramping constraints or not.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

storage_method_energy

  • Description: Whether there is independent investment on storage capacity or not. If false, the investment on storage capacity uses the energytopower_ratio as a constant fixed value.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

technical_lifetime

  • Description: Technical lifetime of the unit to determine for how long the capacity is considered from the commission year.

  • Type: INTEGER

  • Unit of measure: years

  • Default: 1

ConstraintsValue
minimum0

type

  • Description: Type of energy asset.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

ConstraintsValue
oneOfAny["producer", "consumer", "storage", "conversion", "hub"]

unit_commitment

  • Description: Whether asset has unit commitment constraints or not

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

unit_commitment_integer

  • Description: Whether the unit commitment variables are integer or not.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

unit_commitment_method

  • Description: Which unit commitment method to use (null/empty/missing -> no unit commitment method).

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

ConstraintsValue
oneOfAny[nothing, "basic"]

use_binary_storage_method

  • Description: Whether to use an extra binary variable for the storage assets to avoid charging and discharging simultaneously (null/empty/missing -> no binary).

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

ConstraintsValue
oneOfAny[nothing, "binary", "relaxed_binary"]

Table 2 : asset_both

asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

commission_year

  • Description: Year of commissioning

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

decommissionable

  • Description: Whether the asset can be decomission or not.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

initial_storage_units

  • Description: Number of existing storage units

  • Type: DOUBLE

  • Unit of measure: number

  • Default: 0

  • Constraints: No constraints

initial_units

  • Description: Number of existing units

  • Type: DOUBLE

  • Unit of measure: number

  • Default: 0

  • Constraints: No constraints

milestone_year

  • Description: Year of investment and operation decisions in the optimization.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 3 : asset_commission

asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

commission_year

  • Description: Year of commissioning.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

fixed_cost

  • Description: Fixed annual cost for the asset capacity.

  • Type: DOUBLE

  • Unit of measure: CUR/MW/year

  • Default: No default

  • Constraints: No constraints

fixed_cost_storage_energy

  • Description: Fixed annual cost for the asset storage capacity

  • Type: DOUBLE

  • Unit of measure: CUR/MWh/year

  • Default: No default

  • Constraints: No constraints

investment_cost

  • Description: Investment cost for the asset capacity.

  • Type: DOUBLE

  • Unit of measure: CUR/MW

  • Default: No default

  • Constraints: No constraints

investment_cost_storage_energy

  • Description: Investment cost for the asset energy storage capacity.

  • Type: DOUBLE

  • Unit of measure: CUR/MWh

  • Default: No default

  • Constraints: No constraints

investment_limit

  • Description: Maximum capacity for the asset investment. If the initial value is null, empty, or missing, it will be no limit.

  • Type: DOUBLE

  • Unit of measure: MWh

  • Default: No default

  • Constraints: No constraints

investment_limit_storage_energy

  • Description: Maximum capacity for the asset storage investment. If the initial value is null, empty, or missing, it will be no limit.

  • Type: DOUBLE

  • Unit of measure: MWh

  • Default: No default

  • Constraints: No constraints

Table 4 : asset_milestone

asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

initial_storage_level

  • Description: The initial storage level at the beginning of the optimization. The final storage level needs to be above this initial value. If the initial value is null, empty, or missing, it will be optimized using a cycling constraint that links the last period to the initial period.

  • Type: DOUBLE

  • Unit of measure: MWh

  • Default: 0

ConstraintsValue
minimum0

investable

  • Description: Whether there is an investment variable created for the asset or not.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

max_energy_timeframe_partition

  • Description: The maximum amount of energy across the timeframe (e.g., a year) that the asset must produce. If the initial value is null, empty, or missing, it will be no limit.

  • Type: DOUBLE

  • Unit of measure: MWh

  • Default: No default

ConstraintsValue
minimum0

milestone_year

  • Description: Year of investment and operation decisions in the optimization.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

min_energy_timeframe_partition

  • Description: The minimum amount of energy across the timeframe (e.g., a year) that the asset must produce. If the initial value is null, empty, or missing, it will be no limit.

  • Type: DOUBLE

  • Unit of measure: MWh

  • Default: No default

ConstraintsValue
minimum0

peak_demand

  • Description: Value that multiplies the demand profile time series.

  • Type: DOUBLE

  • Unit of measure: MW

  • Default: 0

ConstraintsValue
minimum0

storage_inflows

  • Description: Value that multiplies the inflow profile time series.

  • Type: DOUBLE

  • Unit of measure: MWh/year

  • Default: 0

ConstraintsValue
minimum0

units_on_cost

  • Description: Cost of keeping unit online for one hour or the objective function coefficient on units_on variable. e.g., no_load cost or idling cost

  • Type: DOUBLE

  • Unit of measure: CUR/p.u./h

  • Default: 0

ConstraintsValue
minimum0

Table 5 : assets_profiles

asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

commission_year

  • Description: Year of commissioning

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

profile_name

  • Description: Name of profile, used to determine data inside the DuckDB table

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

profile_type

  • Description: Type of profile, used to determine DuckDB table with source profile

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

ConstraintsValue
oneOfAny["availability", "demand", "inflows", "max_storage_level", "min_storage_level"]

Table 6 : assets_rep_periods_partitions

asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

partition

  • Description: Partition or temporal resolution in the representative periods. For example, for a uniform specification 1 is hourly, 2 is every two hours.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

rep_period

  • Description: Number of the representative period

  • Type: INTEGER

  • Unit of measure: number

  • Default: No default

  • Constraints: No constraints

specification

  • Description: Partition (or temporal resolution) specification in the representative periods.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: uniform

ConstraintsValue
oneOfAny["uniform", "explicit", "math"]

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 7 : assets_timeframe_partitions

asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

partition

  • Description: Partition or temporal resolution in the timeframe. For example, if a period is equivalent to a day then for a uniform specification 1 is per day, 2 is every two days.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

specification

  • Description: Partition (or temporal resolution) specification in the timeframe.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: uniform

ConstraintsValue
oneOfAny["uniform", "explicit", "math"]

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 8 : assets_timeframe_profiles

asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

commission_year

  • Description: Year of commissioning

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

profile_name

  • Description: Name of profile, used to determine data inside the DuckDB table

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

profile_type

  • Description: Type of profile, used to determine DuckDB table with source profile

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

ConstraintsValue
oneOfAny["max_storage_level", "min_storage_level", "max_energy", "min_energy"]

Table 9 : flow

capacity

  • Description: Capacity for one unit of the transport flow (is therefore multiplied by number of existing plus invested number of transport assets).

  • Type: DOUBLE

  • Unit of measure: MW

  • Default: 0

ConstraintsValue
minimum0

carrier

  • Description: Energy carrier

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

discount_rate

  • Description: e.g. 0.05 is 5 %. discount rate for the annuity calculation.

  • Type: DOUBLE

  • Unit of measure: ratio

  • Default: 0

ConstraintsValue
minimum0

economic_lifetime

  • Description: Economic lifetime of the transport asset for annuity calculation.

  • Type: INTEGER

  • Unit of measure: years

  • Default: 1

ConstraintsValue
minimum0

from_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

investment_integer

  • Description: Whether investment decisions are using integer variables.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

is_transport

  • Description: Whether a transport flow or not. Transport assets can have flows in both directions and can be invested in.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

technical_lifetime

  • Description: Technical lifetime of the transport asset to determine for how long the capacity is considered from the commission year.

  • Type: INTEGER

  • Unit of measure: years

  • Default: 1

ConstraintsValue
minimum0

to_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

Table 10 : flow_both

commission_year

  • Description: Year of commissioning

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

decommissionable

  • Description: Whether the transport asset can be decomission or not.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

from_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

initial_export_units

  • Description: Number of existing units in from_asset -> to_asset direction

  • Type: DOUBLE

  • Unit of measure: number

  • Default: 0

  • Constraints: No constraints

initial_import_units

  • Description: Number of existing units in to_asset -> from_asset direction

  • Type: DOUBLE

  • Unit of measure: number

  • Default: 0

  • Constraints: No constraints

milestone_year

  • Description: Year of investment and operation decisions in the optimization.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

to_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

Table 11 : flow_commission

commission_year

  • Description: Year of commissioning

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

efficiency

  • Description: Efficiency of transfer in from_asset -> to_asset direction

  • Type: DOUBLE

  • Unit of measure: ratio

  • Default: 1

ConstraintsValue
minimum0

fixed_cost

  • Description: Fixed annual cost for the transport asset capacity.

  • Type: DOUBLE

  • Unit of measure: CUR/MW/year

  • Default: No default

  • Constraints: No constraints

from_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

investment_cost

  • Description: Investment cost for the transport asset capacity.

  • Type: DOUBLE

  • Unit of measure: CUR/MW

  • Default: No default

  • Constraints: No constraints

investment_limit

  • Description: Maximum capacity for the transport asset investment. If the initial value is null, empty, or missing, it will be no limit.

  • Type: DOUBLE

  • Unit of measure: MWh

  • Default: No default

  • Constraints: No constraints

to_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

Table 12 : flow_milestone

from_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

investable

  • Description: Whether there is an investment variable created for the asset or not.

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: false

  • Constraints: No constraints

milestone_year

  • Description: Year of investment and operation decisions in the optimization.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

to_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

variable_cost

  • Description: Variable cost for the flow.

  • Type: DOUBLE

  • Unit of measure: CUR/MWh

  • Default: 0

  • Constraints: No constraints

Table 13 : flows_profiles

from_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

profile_name

  • Description: Name of profile, used to determine data inside the DuckDB table

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

profile_type

  • Description: Type of profile, used to determine DuckDB table with source profile

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

ConstraintsValue
oneOfAny["availability"]

to_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 14 : flows_rep_periods_partitions

from_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

partition

  • Description: Partition or temporal resolution in the representative periods. For example, for a uniform specification 1 is hourly, 2 is every two hours.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

rep_period

  • Description: Number of the representative period

  • Type: INTEGER

  • Unit of measure: number

  • Default: No default

  • Constraints: No constraints

specification

  • Description: Partition (or temporal resolution) specification in the representative periods.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: uniform

ConstraintsValue
oneOfAny["uniform", "explicit", "math"]

to_asset

  • Description: Name of the asset. Same as the one in the asset table.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 15 : group_asset

invest_method

  • Description: true -> activate group constraints; false -> no group investment constraints

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

max_investment_limit

  • Description: MW (Missing -> no limit)

  • Type: DOUBLE

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

milestone_year

  • Description: Year of investment and operation decisions in the optimization.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

min_investment_limit

  • Description: MW (Missing -> no limit)

  • Type: DOUBLE

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

name

  • Description: Name of the Group

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

Table 16 : profiles_rep_periods

profile_name

  • Description: Profile name.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

rep_period

  • Description: Representative period number.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

timestep

  • Description: Timestep number.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

value

  • Description: Value of the profile.

  • Type: DOUBLE

  • Unit of measure: p.u.

  • Default: No default

  • Constraints: No constraints

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 17 : profiles_timeframe

period

  • Description: Period.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

profile_name

  • Description: Profile name.

  • Type: VARCHAR

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

value

  • Description: value of the profile.

  • Type: DOUBLE

  • Unit of measure: p.u.

  • Default: No default

  • Constraints: No constraints

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 18 : rep_periods_data

num_timesteps

  • Description: Number of timesteps

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 8760

  • Constraints: No constraints

rep_period

  • Description: Representative period number.

  • Type: INTEGER

  • Unit of measure: number

  • Default: 1

  • Constraints: No constraints

resolution

  • Description: Duration of each timestep

  • Type: DOUBLE

  • Unit of measure: hours

  • Default: 1

  • Constraints: No constraints

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 19 : rep_periods_mapping

period

  • Description: Period number.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

rep_period

  • Description: Representative period number.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

weight

  • Description: Hours

  • Type: DOUBLE

  • Unit of measure: No unit

  • Default: 1

  • Constraints: No constraints

year

  • Description: Milestone year.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 20 : timeframe_data

num_timesteps

  • Description: Number of timesteps of the representative period.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 8760

  • Constraints: No constraints

period

  • Description: Period.

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: No default

  • Constraints: No constraints

year

  • Description: Unique identifier (currently, the year itself)

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints

Table 21 : year_data

is_milestone

  • Description: Whether the year is a milestone year or a vintage year

  • Type: BOOLEAN

  • Unit of measure: No unit

  • Default: true

  • Constraints: No constraints

length

  • Description: How many hours in a year, e.g., 8760

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 8760

  • Constraints: No constraints

year

  • Description: Unique identifier (currently, the year itself)

  • Type: INTEGER

  • Unit of measure: No unit

  • Default: 2000

  • Constraints: No constraints
